Pressure sensors
Pressure transmitters with casing (voltage output)
Characteristics
CAU-T series
V A0 + V FS
V A0
Simple output (AUA, AUR)
V A0 + ?V FS
V A0
V A0 - ?V FS
Symmetrical output (AUS)
0
p r
-p r
0
+p r
Connection diagram
V cc
V cc
p
U
GND
V A
GND
p
V A
U
GND A
3-wire connection (standard)
4-wire connection (option for long cable)
GND and GND A are internally connected.
To avoid ground loops, it is not allowed to
connect GND and GND A at the end of the
cable.
Terminal assignment
Electrical connection
Supply voltage
Ground
Symbol
V cc
GND
Pin (color)
1 (brown)
3 (blue)
4
1
3
2
Output signal (referenced to GND)
Ground (Kelvin guidance)
V A
GND A
2 (white)
4 (black)
Venting hole
?2 mm
AS SEN PD
Please read Cautions and warnings and
Important notes at the end of this document .
Page 4 of 8
2009-08-03
